| Properties |
DCM35 (USB1.0) |
DCM35 (USB2.0) |
| Image Sensor |
1/3 CMOS of 350K pixels, offering color image |
| MAX Resolution (Still) |
640 x 480, pixel size 8µm x 8µm |
| MAX Resolution (Motion) |
15 frame/sec at 640 x 480;
30 frame/sec at 320 x 240; |
30 frame/sec at 640 x 480;
30 frame/sec at 320 x 240; |
| View Field |
Inscribed rectangle of φ 18mm |
| Usage |
Ocular-tube, photo-tube on microscope |
| Sensitivity |
2.7v/lux.sec@green
2.1v/lux.sec@red
2.0v/lux.sec@blue |
| File Format |
BMP. TIFF, JPG, PICT, PTL etc. |
| Exposure |
Automatic |
| Shutter Control |
Automatic |
| Interface |
USB, hot plug and thrust, a USB cable of length 2m |
| System Requirement |
Windows 2000 / XP; USB cable |
| Software |
Driver
Software "MiniSee" included with DCM35
Software "ScopePhoto"available for option at extra cost
Photoshop plug-in; |
| Weight |
4.8 oz without eyepiece adapter |
| Camera Size |
Cylinder shape, φ50mm |
| Camera Body |
Blackened metal body of cylinder shape |
Note:
1) All detailed function should refer to the software MinSee, SCOPETEK
has the rights to change the function without notifications.
2) All detailed function should refer to the software ScopePhoto, SCOPETEK
has the right to change the function without notifications.
3) Please keep contact with our distributors for the further information
about our new products, such as DCM130 and DCM210. |
Features
1) DCM35 employs newly designed optical system of fully coated, based on
MTF (modulation Transfer Function) analysis, for improved image flatness
and contrast. The images are brighter and distinct even at the periphery
of the field of view. It offers excellent performance when combined with
plan-achromatic objectives system. Especially, this system is designed
for microscope and matches the specific characters of microscope, such
as the field of view of eyepiece WF10x-18mm and the parfocalization of
objectives
2) DCM35 has a wide field, which matches microscope's field of view 18mm.
3) For any observation head from microscope, i.e. monocular head, binocular
head or trinocular head, DCM35 can be inserted directly into the ocular-tube
of the photo-tube. With the adaptor φ30mm or the adaptor φ30.5mm
included, it is also workable on a stereomicroscope. The operation is so
simple that it can works perfectly with all kinds of microscopes.
4) If the microscope adapted with DCM35 is earthed definitely, the metal
body of DCM35 ensures wonderful anti-interference.
5) Based on the consideration of the color temperature of microscope illumination,
the design makes it offer very good color fidelity. The captured image
is available with true color.
|
|
