Range |
30mΩ, 300mΩ, 3Ω, 30Ω,
300Ω, 3kΩ 30kΩ, 300kΩ and 3MΩ 9ranges |
Accuracy |
30mΩ: ±1% reading + 6
digits
300mΩ: ±0.05% reading + 6 digits
3Ω: ±0.05% reading +
3digits
30Ω~3MΩ: ±0.05% reading + 2 digits |
Function |
Hi/Lo, Go/No-Go,
Trigger, %, Diode, REL, Temp, TC |
Measuring Rate
|
7 measuring/sec at
30,000 counts ;
30 measuring/sec at 3,000 counts |
Interface |
Standard: Handler,
Scan (same connector)
Option: RS-232C, GPIB |
Power
Source |
AC 110V, 120V, 220V,
230V±10%, 50/60Hz |
Accessories |
Power cord
x1
Instruction manual ×1,
Test lead GTL-108A ×1,
Option: PT-100
Temperature Probe (K-Type) |
Dimensions &
Weight |
251(W)×91(H)×291(D)
mm, Approx. 2kg |
