SPECIFICATIONS |
Main
Output |
|
|
Frequency |
100kHz ~ 150MHz (up
to 450MHz on harmonics) |
| Range |
A 100 ~
290kHz |
| B 290 ~
900kHz |
| C 0.9 ~
3.0MHz |
| D 3.0 ~
11MHz |
| E 10 ~
35MHz |
| F 32 ~
150MHz |
| (96 ~ 450MHz,
calibrated harmonics) |
|
Accuracy |
+5% |
| Level |
100mVrms approx up
to 35MHz |
| Level
control |
High/Low switch able
and fine control |
|
| Amplitude
Modulation |
|
Internal |
Frequency：1kHz |
| Percentage：30% max
and adjuster |
|
External |
Frequency：50Hz to
20kHz |
| Sensitivity：less
than 1Vrms |
|
| AUX
Output |
Audio Output
Frequency：1kHz |
| Level：1Vrms MIN,
fixed |
|
| Frequency
Monitor |
Frequency：Oscillation frequency |
| Level：50mVrms
MIN |
|
| Power
Source |
AC 100/115/230V
+10%, 50/60Hz |
|
|
Accessories |
Power cord x 1,
Instruction manual x 1,
GTL-110 x 1 |
|
| Dimensions &
Weight |
247(W) x 158(H) x
140(D) mm, Approx. 2.5kg |
