Specifications
|
1 side machine |
1 side machine |
2 sides machine |
Professional machine |
Drilling machine |
|
Model
|
ZY2518
|
ZY2518-A
|
ZY3222A
|
ZY5038
|
ZY1200
|
| PCB |
one side board
|
one side board
|
two sides board
|
two sides board
|
- |
|
Working Area( cm)
|
25 x 18
|
25 x 18
|
32x22
|
50 x 38
|
32x22
|
|
Speed( m/ min)
|
1.8
|
2.4
|
4.5
|
5.4
|
2.4
|
|
Precision( mil)
|
15
|
12
|
8
|
6
|
- |
|
Communication
|
RS-232
|
RS-232
|
RS-232
|
USB
|
RS-232
|
|
Band Rate( bps)
|
57600
|
57600
|
57600
|
200000
|
57600
|
|
RPM( r/min)
|
32000
|
32000
|
32000
|
32000
|
12000
|
|
Power
|
AC220V 50Hz
|
AC220V 50Hz
|
AC220V 50Hz
|
AC220V 50Hz
|
AC220V 50Hz
|
|
OS
|
Win98/2000/XP
|
Win98/2000/XP
|
Win98/2000/XP
|
Win98/2000/XP
|
Win98/2000/XP
|
|
Memory( MB)
|
256
|
256
|
512
|
512
|
256
|
|
Dimension(cm)
|
50x50x46
|
50x50x46
|
60?0?6
|
80x80x60
|
54x46x41
|
|
Weight( Kg)
|
68
|
68
|
76
|
125
|
25
|
|
Accessories
(route knife)
|
10
|
10
|
10
|
20
|
- |
| Accessories
(drill tips)
|
10
|
10
|
10
|
20
|
10
|
| Electroplating |
- |
- |
Option |
Option |
- |
|
Motor
|
No-brush DC motor (DC motors available)
|
| Price |
$3495
|
$3795
|
$6495
|
$15,995
|
$2275
|
|
|
|
|
|
|
|
