Madell Technology Corporation

Model	Output	Size	Military($)	Industrial($)	Commercial($)
AT-QK5-5A	5V5A	130 x 85 x 30	462	230	154
AT-QK5-8A	5V8A	140 x 85 x 30	490	244	162
AT-QK5-10A	5V10A	150 x 90 x 35	508	254	168
AT-QK5-15A	5V15A	160 x 100 x 35	570	284	190
AT-QK5-20A	5V20A	180 x 120 x 35	700	350	232
AT-QK5-25A	5V25A	200 x 120 x 50	738	368	246
AT-QK5-30A	5V30A	220 x 140 x 50	760	380	252
AT-QK5-35A	5V35A	240 x 140 x 50	808	404	268
AT-QK5-40A	5V40A	260 x 140 x 50	848	424	282
AT-QK5-50A	5V50A	260 x 160 x 60	1008	504	336
AT-QK5-60A	5V60A	260 x 180 x 80	1062	530	354
AT-QK5-80A	5V80A	280 x 180 x 80	1500	750	500
AT-QK5-100AF	5V100A	300 x 220 x 125	1582	790	526
AT-QK5-150AF	5V150A	380 x 130 x 230	2910	1454	970
AT-QK5-200AF	5V200A	420 x 170 x 260	4050	2024	1350
AT-QK5-300AF	5V300A	450 x 210 x 290	6144	3072	2048
AT-QK5-400AF	5V400A	500 x 240 x 320	8122	4060	2706
AT-QK5-500AF	5V500A	500 x 270 x 440	10210	5104	3402
AT-QK5-600AF	5V600A	550 x 300 x 470	11730	5864	3990
AT-QK5-700AF	5V700A	550 x 300 x 500	12984	6492	4328
AT-QK5-800AF	5V800A	620 x 420 x 530	14838	7418	4946
AT-QK5-900AF	5V900A	620 x 450 x 560	16692	8350	5564
AT-QK6-5A	6V5A	130 x 85 x 30	546	272	182
AT-QK6-8A	6V8A	140 x 85 x 30	700	350	232
AT-QK6-10A	6V10A	150 x 90 x 35	728	364	242
AT-QK6-15A	6V15A	160 x 100 x 35	808	404	268
AT-QK6-20A	6V20A	180 x 120 x 35	998	498	332
AT-QK6-25A	6V25A	200 x 120 x 50	1062	530	354
AT-QK6-30A	6V30A	220 x 140 x 50	1454	726	484
AT-QK6-35A	6V35A	240 x 140 x 50	1572	786	524
AT-QK6-40A	6V40A	260 x 140 x 50	1740	870	580
AT-QK6-50A	6V50A	260 x 160 x 60	2250	1124	750
AT-QK6-60A	6V60A	260 x 180 x 80	2790	1394	930
AT-QK6-80A	6V80A	280 x 180 x 80	3360	1680	1120
AT-QK6-100A	6V100A	300 x 220 x 125	4140	2070	1380
AT-QK6-150AF	6V150A	380 x 130 x 230	5780	2890	1926
AT-QK6-200AF	6V200A	420 x 170 x 260	7568	3784	2522
AT-QK6-300AF	6V300A	450 x 210 x 290	10986	5492	3662
AT-QK6-400AF	6V400A	500 x 240 x 320	15590	7794	5196
AT-QK6-500AF	6V500A	500 x 270 x 440	19488	9744	6496
AT-QK6-600AF	6V600A	550 x 300 x 470	23760	11880	7920
AT-QK6-700AF	6V700A	550 x 300 x 500	27720	13860	9240
AT-QK6-800AF	6V800A	620 x 420 x 530	31680	15840	10560
AT-QK6-900AF	6V900A	620 x 450 x 560	35640	17820	11880
AT-QK9-10A	9V10A	150 x 100 x 35	786	360	240
AT-QK9-15A	9V15A	160 x 100 x 35	786	392	262
AT-QK9-20A	9V20A	180 x 120 x 35	936	468	312
AT-QK9-25A	9V25A	200 x 120 x 50	1002	500	334
AT-QK9-30A	9V30A	220 x 140 x 50	1392	696	464
AT-QK9-35A	9V35A	240 x 140 x 50	1512	756	504
AT-QK9-40A	9V40A	260 x 140 x 50	1668	834	556
AT-QK9-50A	9V50A	260 x 180 x 80	2160	1080	720
AT-QK9-60A	9V60A	280 x 180 x 80	3420	1710	1140
AT-QK9-80A	9V80A	300 x 180 x 80	4140	2070	1380
AT-QK9-100AF	9V100A	380 x 130 x 230	5100	2550	1700
AT-QK9-150AF	9V150A	380 x 130 x 230	7140	3570	2380
AT-QK9-200AF	9V200A	420 x 170 x 260	9360	4680	3120
AT-QK9-300AF	9V300A	450 x 210 x 290	13560	6780	4520
AT-QK9-400AF	9V400A	500 x 240 x 320	19368	9684	6456
AT-QK9-500AF	9V500A	500 x 270 x 440	24240	12120	8080
AT-QK9-600AF	9V600A	550 x 300 x 470	30120	15060	10040
AT-QK12-2A	12V2A	120 x 85 x 30	462	230	154
AT-QK12-3A	12V3A	120 x 85 x 30	490	244	162
AT-QK12-4A	12V4A	130 x 85 x 30	508	254	168
AT-QK12-5A	12V5A	130 x 90 x 35	546	272	182
AT-QK12-6A	12V6A	150 x 90 x 35	570	284	190
AT-QK12-8A	12V8A	160 x 100 x 35	700	350	232
AT-QK12-10A	12V10A	170 x 120 x 35	788	394	242
AT-QK12-15A	12V15A	200 x 140 x 50	808	404	268
AT-QK12-20A	12V20A	210 x 140 x 50	998	498	332
AT-QK-12-25A	12V25A	260 x 140 x 50	1062	530	354
AT-QK-12-30A	12V30A	260 x 160 x 60	1454	726	484
AT-QK-12-35A	12V35A	280 x 160 x 60	1572	786	524
AT-QK-12-40A	12V40A	280 x 160 x 60	1740	870	580
AT-QK-12-50A	12V50A	280 x 180 x 80	2250	1124	750
AT-QK-12-60A	12V60A	280 x 220 x 125	3486	1742	1162
AT-QK-12-80AF	12V80A	380 x 130 x 230	4200	2100	1400
AT-QK-12-100AF	12V100A	380 x 130 x 230	5174	2586	1724
AT-QK-12-120AF	12V120A	400 x 170 x 260	6144	3072	2048
AT-QK-12-150AF	12V150A	400 x 170 x 260	7224	3612	2408
AT-QK-12-180AF	12V180A	450 x 210 x 290	8416	4208	2804
AT-QK-12-200AF	12V200A	450 x 210 x 290	9460	4730	3152
AT-QK-12-250AF	12V250A	480 x 240 x 320	11130	5564	3710
AT-QK-12-300AF	12V300A	500 x 240 x 320	13732	6866	4576
AT-QK-12-350AF	12V350A	550 x 270 x 440	16518	8258	5506
AT-QK-12-400AF	12V400A	550 x 270 x 440	19488	9744	6496
AT-QK-12-500AF	12V500A	650 x 300 x 470	24360	12180	8120
AT-QK-12-600AF	12V600A	650 x 300 x 500	30240	15120	10080
AT-QK-12-700AF	12V700A	720 x 420 x 530	35280	17640	11760
AT-QK-12-800AF	12V800A	720 x 450 x 560	40320	20160	13440
AT-QK-13.8-5A	13.8V5A	140 x 90 x 35	570	284	190
AT-QK-13.8-8A	13.8V8A	170 x 120 x 35	728	364	242
AT-QK-13.8-10A	13.8V10A	180 x 120 x 50	760	380	252
AT-QK-13.8-15A	13.8V15A	200 x 140 x 50	986	492	328
AT-QK-13.8-20A	13.8V20A	260 x 140 x 74	1062	530	354
AT-QK-13.8-25A	13.8V25A	260 x 140 x 50	1454	726	484
AT-QK-13.8-30A	13.8V30A	280 x 160 x 60	1548	774	516
AT-QK-13.8-35A	13.8V35A	280 x 160 x 60	1590	794	530
AT-QK-13.8-40A	13.8V40A	280 x 160 x 60	1650	824	550
AT-QK-13.8-50A	13.8V50A	260 x 220 x 125	2910	1455.60	970
AT-QK-13.8-100AF	13.8V100A	400 x 170 x 260	6144	3072	2048
AT-QK-13.8-200AF	13.8V200A	480 x 240 x 320	11130	5564	3710
AT-QK-15-2A	15V2A	120 x 85 x 30	472	236	156
AT-QK-15-3A	15V3A	130 x 85 x 30	498	248	166
AT-QK-15-4A	15V4A	150 x 90 x 35	546	272	182
AT-QK-15-5A	15V5A	160 x 90 x 35	5870	284	190
AT-QK-15-6A	15V6A	150 x 100 x 35	668	334	222
AT-QK-15-8A	15V8A	170 x 120 x 35	728	364	242
AT-QK-15-10A	15V10A	180 x 120 x 35	764	382	252
AT-QK-15-15A	15V15A	210 x 140 x 50	986	492	328
AT-QK-15-20A	15V20A	260 x 140 x 50	1140	570	380
AT-QK-15-25A	15V25A	260 x 160 x 60	1454	726	484
AT-QK-15-30A	15V30A	260 x 160 x 60	1590	794	530
AT-QK-15-35A	15V35A	280 x 180 x 80	1722	860	574
AT-QK-15-40A	15V40A	280 x 180 x 80	2040	1020	680
AT-QK-15-50AF	15V50A	280 x 220 x 125	3638	1818	1212
AT-QK-15-60AF	15V60A	380 x 130 x 230	4050	2024	1350
AT-QK-15-80AF	15V80A	380 x 130 x 230	4500	2250	1500
AT-QK-15-100AF	15V100A	400 x 170 x 260	5624	2812	1874
AT-QK-15-120AF	15V120A	400 x 170 x 260	6474	3238	2158
AT-QK-15-150AF	15V150A	450 x 210 x 290	8574	4282	2854
AT-QK-15-180AF	15V180A	480 x 240 x 320	10578	5288	3526
AT-QK-15-200AF	15V200A	480 x 240 x 320	12600	6300	4200
AT-QK-15-250AF	15V250A	550 x 270 x 440	15488	7744	5162
AT-QK-15-300AF	15V300A	550 x 270 x 440	18606	9302	6202
AT-QK-15-350AF	15V350A	600 x 300 x 470	21706	10852	7234
AT-QK-15-400AF	15V400A	650 x 300 x 470	24806	12402	8268
AT-QK-18-5A	18V5A	150 x 100 x 35	668	334	222
AT-QK-18-8A	18V8A	180 x 120 x 35	760	380	252
AT-QK-18-10A	18V10A	200 x 120 x 35	808	404	268
AT-QK-18-15A	18V15A	240 x 140 x 50	1030	514	342
AT-QK-18-20A	18V20A	260 x 140 x 50	1454	726	284
AT-QK-18-25A	18V25A	280 x 160 x 60	1548	774	516
AT-QK-18-30A	18V30A	280 x 180 x 80	1608	804	536
AT-QK-18-40A	18V40A	280 x 220 x 125	3638	1818	1212
AT-QK-18-50A	18V50A	380 x 130 x 230	3900	1950	1300
AT-QK-18-60A	18V60A	380 x 130 x 230	5024	2512	1674
AT-QK-18-100AF	18V100A	400 x 170 x 260	6462	3238	2158
AT-QK-18-200AF	18V200A	500 x 240 x 320	13732	6866	4576
AT-QK-24-1A	24V1A	120 x 85 x 30	462	231.60	154
AT-QK-24-2A	24V2A	120 x 85 x 30	508	254.60	168
AT-QK-24-2.5A	24V2.5A	130 x 90 x 35	546	272	182
AT-QK-24-3A	24V3A	140 x 90 x 35	570	284	190
AT-QK-24-4A	24V4A	160 x 100 x 35	700	350	232
AT-QK-24-5A	24V5A	170 x 120 x 35	728	364	242
AT-QK-24-6A	24V6A	180 x 120 x 35	760	380	252
AT-QK-24-8A	24V8A	200 x 120 x 35	848	424	282
AT-QK-24-10A	24V10A	210 x 140 x 50	998	498	332
AT-QK-24-12A	24V12A	240 x 140 x 50	1052	526	350
AT-QK-24-15A	24V15A	260 x 140 x 50	1454	726	484
AT-QK-24-18A	24V18A	280 x 160 x 60	1608	804	536
AT-QK-24-20A	24V20A	280 x 160 x 60	1788	894	596
AT-QK-24-25A	24V25A	280 x 180 x 80	2040	1020	680
AT-QK-24-30A	24V30A	280 x 220 x 125	3450	1724	1150
AT-QK-24-35AF	24V35A	380 x 130 x 230	3824	1912	1274
AT-QK-24-40AF	24V40A	380 x 130 x 230	4350	2174	1450
AT-QK-24-45AF	24V45A	380 x 130 x 230	4800	2400	1600
AT-QK-24-50AF	24V50A	400 x 130 x 230	5450	2700	1800
AT-QK-24-55AF	24V55A	400 x 170 x 260	6100	3150	2100
AT-QK-24-60AF	24V60A	400 x 170 x 260	6400	3250	2200
AT-QK-24-80AF	24V80A	450 x 210 x 290	7990	3990	2690
AT-QK-24-90AF	24V90A	450 x 210 x 290	8990	4500	2990
AT-QK-24-100AF	24V100A	450 x 210 x 290	9890	4890	3350
AT-QK-24-120AF	24V120A	480 x 240 x 320	11580	5990	3890
AT-QK-24-130AF	24V130A	500 x 240 x 320	13200	6650	4500
AT-QK-24-150AF	24V150A	500 x 240 x 320	15380	7800	5400
AT-QK-24-180AF	24V180A	550 x 270 x 440	17900	8900	5990
AT-QK-24-200AF	24V200A	550 x 270 x 440	21000	10500	7400
AT-QK-24-250AF	24V250A	650 x 300 x 470	24900	12900	8600
AT-QK-24-300AF	24V300A	650 x 300 x 500	29500	15500	9900
AT-QK-24-350AF	24V350A	720 x 420 x 530	37500	18500	12900
AT-QK-24-400AF	24V400A	720 x 450 x 560	39900	21000	13900
AT-QK-24-500AF	24V500A	760 x 510 x 620	52250	25900	17900
AT-QK28-1.5A	28V1.5A	120 x 85 x 30	498	248	166
AT-QK28-2A	28V2A	130 x 90 x 35	546	272	182
AT-QK28-3A	28V3A	150 x 100 x 35	652	326	216
AT-QK28-4A	28V4A	170 x 120 x 35	728	364	242
AT-QK28-5A	28V5A	180 x 120 x 35	750	374	250
AT-QK28-6A	28V6A	190 x 120 x 35	790	394	262
AT-QK28-8A	28V8A	210 x 140 x 50	986	492	328
AT-QK28-10A	28V10A	230 x 140 x 50	1040	520	346
AT-QK28-12A	28V12A	260 x 140 x 50	1410	704	470
AT-QK28-15A	28V15A	280 x 160 x 60	1530	764	510
AT-QK28-18A	28V18A	280 x 180 x 80	1614	806	538
AT-QK28-20A	28V20A	280 x 180 x 80	2040	1020	680
AT-QK28-25A	28V25A	260 x 220 x 125	2820	1410	940
AT-QK28-30AF	28V30A	380 x 130 x 230	3824	1912	1274
AT-QK28-35AF	28V35A	380 x 130 x 230	4050	2024	1350
AT-QK28-40AF	28V40A	380 x 130 x 230	4350	2174	1450
AT-QK28-45AF	28V45A	400 x 170 x 260	5824	2962	1974
AT-QK28-50AF	28V50A	400 x 170 x 260	6034	3016	2010
AT-QK28-55AF	28V55A	400 x 170 x 260	6254	3126	2084
AT-QK28-60AF	28V60A	400 x 170 x 260	6750	3374	2250
AT-QK28-70AF	28V70A	450 x 210 x 290	8122	4060	2706
AT-QK28-80AF	28V80A	450 x 210 x 290	8924	4462	2974
AT-QK28-90AF	28V90A	480 x 240 x 320	10394	5196	3464
AT-QK28-100AF	28V100A	480 x 240 x 320	10762	5380	3586
AT-QK28-120AF	28V120A	500 x 240 x 320	13290	6644	4430
AT-QK28-140AF	28V140A	550 x 270 x 440	16004	8002	5334
AT-QK28-160AF	28V160A	550 x 270 x 440	18606	9302	6202
AT-QK28-180AF	28V180A	600 x 300 x 470	21650	10824	7216
AT-QK28-200AF	28V200A	650 x 300 x 470	24510	12254	8170
AT-QK28-250AF	28V250A	650 x 300 x 500	30636	15318	10212
AT-QK28-300AF	28V300A	720 x 420 x 530	36764	18382	12254
AT-QK28-400AF	28V400A	760 x 510 x 620	49016	24508	16338
AT-QK30-3A	30V3A	160 x 100 x 35	668	322	222
AT-QK30-5A	30V5A	180 x 120 x 35	760	380	252
AT-QK30-10A	30V10A	260 x 140 x 50	1062	530	354
AT-QK30-15A	30V15A	280 x 160 x 60	1548	774	516
AT-QK30-20A	30V20A	280 x 160 x 80	2160	1080	720
AT-QK30-30A	30V30A	380 x 130 x 230	3900	1950	1300
AT-QK30-50AF	30V50A	400 x 170 x 260	6144	3072	2048
AT-QK48-1A	48V1A	150 x 100 x 35	508	254	168
AT-QK48-2A	48V2A	170 x 100 x 35	700	350	232
AT-QK48-3A	48V3A	180 x 120 x 35	760	380	252
AT-QK48-4A	48V4A	200 x 120 x 35	848	424	282
AT-QK48-5A	48V5A	210 x 140 x 50	998	498	332
AT-QK48-6A	48V6A	240 x 140 x 50	1110	554	370
AT-QK48-8A
