l
Can be used for any surface mount components.
l
Can also be used for two sides PCB boards.
l
Lead-free reflow capable.
l
Great for repair preheating.
l
Temperature to 320°C.
l
Glass view window.
l
IR+hot air heating. Fan cooling.
l
Heating area: 310mmx210mm (Max PCB size: 350mmx245mm).
l
Dimension: 610x440x310mm.
l
Temperature uniformity ±2°C.
l
Working cycle 3±1 minutes per board.
l
Manual draw.
l 10, 20 or 40 profile control points.
l
Stores one, two or four profiles.
l No computer interface..
l
No datalog.
l
Max. power: 3.7KW, average 1.4KW, 220V. We have transformers for 110V power supply.
l
Weight: 39Kg without the packing material.
