Specifications:
l
Frequency range: 1-1000Mhz.
l
Display: 8 digits LED.
l
Gate:
0.01S, 0.1S, 1S, 10S.
l
Precision: 1Hz
l
Sensitivity:
0-10 MHz 10mV, 10Hz-100Mhz 25mV, 100MHz-1000Mhz 25mV.
l
Input impedance: 1M ohm Channel A, B, 50 ohm Channel C.
l
Max input voltage: 150Vrms Channel A, B, 5V rms Channel C.
l
Max aging rate: 5ppm/year.
l
Dimension: 210x230x76mm.
l
Weight: About 5 pounds.
|
